Hyundai IONIQ 5 Long Range AWD(MY22)
Hyundai logo
Hyundai

Hyundai IONIQ 5 Long Range AWD(MY22)

Available SUV AWD
59.200 € $63,936£50,320
385 km239 mi
Range
74
kWh
5.1s
0-100
239
kW

Performance

Power 239 kW (325 hp)
Torque 605 Nm
Acceleration 0-100 km/h 5.1 s
Top Speed 185 km/h115 mph
Drive Type AWD
Electric Range (WLTP) 385 km239 mi

Battery

Battery Capacity (usable) 74 kWh
Battery Capacity (nominal) 77.4 kWh
Battery Type Lithium-ion
Cathode Material NMC
Architecture 800 V
Nominal Voltage 697 V
Number of Cells 384
Pack Configuration 192s2p
Form Factor Pouch
Warranty 8 years / 160,000 km99 mi

Real Range

City (Winter -10°C) 380 km236 mi
Highway (Winter -10°C) 275 km171 mi
Combined (Winter -10°C) 325 km202 mi
City (Summer 23°C) 560 km348 mi
Highway (Summer 23°C) 350 km217 mi
Combined (Summer 23°C) 435 km270 mi

Real Energy Consumption

City (Winter -10°C) 195 Wh/km314 Wh/mi
Highway (Winter -10°C) 269 Wh/km433 Wh/mi
Combined (Winter -10°C) 228 Wh/km367 Wh/mi
City (Summer 23°C) 132 Wh/km212 Wh/mi
Highway (Summer 23°C) 211 Wh/km340 Wh/mi
Combined (Summer 23°C) 170 Wh/km274 Wh/mi

Energy Consumption

EVDB Range 385 km239 mi
EVDB Vehicle Consumption 192 Wh/km309 Wh/mi
Fuel Equivalent (vehicle) 2.2 l/100km

Bidirectional Charging (V2X / BPT)

V2L (Vehicle-to-Load) Yes
V2L Max Power 3.6 kW AC
V2H AC (Vehicle-to-Home) No
V2H DC (Vehicle-to-Home) No
V2G AC (Vehicle-to-Grid) No
V2G DC (Vehicle-to-Grid) No

Dimensions & Weight

Length 4635 mm182.5 in
Width 2152 mm84.7 in
Width (with mirrors) 2152 mm84.7 in
Height 1605 mm63.2 in
Wheelbase 3000 mm118.1 in
Weight 2,120 kg4,674 lbs
Gross Vehicle Weight (GVWR) 2560 kg5,644 lbs
Max Payload 515 kg1,135 lbs
Cargo Volume 527 L18.6 cu ft
Cargo Volume (max) 1578 L55.7 cu ft
Frunk Volume 24 L0.8 cu ft
Roof Load 80 kg176 lbs
Tow Hitch Yes
Towing Capacity (unbraked) 750 kg1,653 lbs
Towing Capacity (braked) 1,600 kg3,527 lbs
Max Vertical Load 100 kg220 lbs

Miscellaneous

Seats 5 people
Isofix Yes, 2 seats
Turning Circle 12 m39.4 ft
Platform HMG E-GMP
EV Platform Yes
Body Type SUV
Segment JC - Medium
Roof Rails No
Heat Pump Yes
Heat Pump (Standard) No, optional

Safety (Euro NCAP)

Rating 5 ★ (2021)
Adult Occupant 88%
Child Occupant 86%
Vulnerable Road Users 63%
Safety Assist 88%

Home Charging (0 → 100%)

Charge Port Type 2
Port Location Right Side - Rear
Charge Power 11 kW AC
Charge Time 8 hours
Charge Speed 49 km/h30 mph

DC Fast Charging (10 → 80%)

Charge Port CCS
Port Location Right Side - Rear
Max. Power 233 kW DC
Avg. Power (10-80%) 196 kW DC
Charge Time 8 hours
Charge Speed 49 km/h30 mph
Autocharge Yes
Charge 20-80% 11 min
Charge 10-90% 15 min

Plug & Charge

Supported No

Battery Preconditioning

Preconditioning Yes
Auto via Navigation Yes

Range Estimation

642 km399 mi
City
385 km239 mi
Combined (WLTP)
275 km171 mi
Highway

Real-World Range

275 km171 mi 560 km348 mi

Efficiency: 192 Wh/km309 Wh/mi

Real-world range varies based on temperature, speed, driving style, and terrain.

Long Distance Rating

3.0/ 5.0
Good

This rating considers:

  • Real highway range (WLTP: 385 km239 mi)
  • Charging speed and charging time
  • Vehicle efficiency

Quick Overview

  • Brand Hyundai
  • WLTP Range 385 km239 mi
  • Battery Capacity 74 kWh
  • DC Fast Charging 233 kW
  • Towing Capacity 1,600 kg3,527 lbs
  • Release Date 4/1/2022
