Nissan Townstar EV Passenger
Nissan logo
Nissan

Nissan Townstar EV Passenger

Available Van FWD
39.990 € $43,189£33,992
225 km140 mi
Range
45
kWh
12.6s
0-100
90
kW

Performance

Power 90 kW (122 hp)
Torque 245 Nm
Acceleration 0-100 km/h 12.6 s
Top Speed 132 km/h82 mph
Drive Type FWD
Electric Range (WLTP) 225 km140 mi

Battery

Battery Capacity (usable) 45 kWh
Battery Capacity (nominal) 48.0 kWh
Battery Type Lithium-ion
Cathode Material NMC
Architecture 400 V
Nominal Voltage 355 V
Warranty 8 years / 160,000 km99 mi

Real Range

City (Winter -10°C) 230 km143 mi
Highway (Winter -10°C) 155 km96 mi
Combined (Winter -10°C) 190 km118 mi
City (Summer 23°C) 335 km208 mi
Highway (Summer 23°C) 200 km124 mi
Combined (Summer 23°C) 255 km158 mi

Real Energy Consumption

City (Winter -10°C) 196 Wh/km315 Wh/mi
Highway (Winter -10°C) 290 Wh/km467 Wh/mi
Combined (Winter -10°C) 237 Wh/km381 Wh/mi
City (Summer 23°C) 134 Wh/km216 Wh/mi
Highway (Summer 23°C) 225 Wh/km362 Wh/mi
Combined (Summer 23°C) 176 Wh/km283 Wh/mi

Energy Consumption

EVDB Range 225 km140 mi
EVDB Vehicle Consumption 200 Wh/km322 Wh/mi
Fuel Equivalent (vehicle) 2.2 l/100km

Bidirectional Charging (V2X / BPT)

V2L (Vehicle-to-Load) No
V2H AC (Vehicle-to-Home) No
V2H DC (Vehicle-to-Home) No
V2G AC (Vehicle-to-Grid) No
V2G DC (Vehicle-to-Grid) No

Dimensions & Weight

Length 4488 mm176.7 in
Width 2159 mm85.0 in
Width (with mirrors) 2159 mm85.0 in
Height 1838 mm72.4 in
Wheelbase 2716 mm106.9 in
Weight 1,872 kg4,127 lbs
Gross Vehicle Weight (GVWR) 2370 kg5,225 lbs
Max Payload 573 kg1,263 lbs
Cargo Volume 819 L28.9 cu ft
Cargo Volume (max) 1730 L61.1 cu ft
Frunk Volume 0 L0.0 cu ft
Roof Load 80 kg176 lbs
Tow Hitch Yes
Towing Capacity (unbraked) 750 kg1,653 lbs
Towing Capacity (braked) 1,500 kg3,307 lbs
Max Vertical Load 75 kg165 lbs

Miscellaneous

Seats 5 people
Isofix Yes, 3 seats
Turning Circle 11.3 m37.1 ft
Body Type Van
Segment N - Passenger Van
Roof Rails Yes
Heat Pump Yes
Heat Pump (Standard) No, optional

Home Charging (0 → 100%)

Charge Port Type 2
Port Location Front Side - Middle
Charge Power 11 kW AC
Charge Time 5 hours
Charge Speed 47 km/h29 mph

DC Fast Charging (10 → 80%)

Charge Port CCS
Port Location Front Side - Middle
Max. Power 80 kW DC
Avg. Power (10-80%) 50 kW DC
Charge Time 5 hours
Charge Speed 47 km/h29 mph
Autocharge Yes
Charge 20-80% 20 min
Charge 10-90% 27 min

Plug & Charge

Supported No

Battery Preconditioning

Preconditioning No
Auto via Navigation No

Range Estimation

375 km233 mi
City
225 km140 mi
Combined (WLTP)
161 km100 mi
Highway

Real-World Range

155 km96 mi 335 km208 mi

Efficiency: 200 Wh/km322 Wh/mi

Real-world range varies based on temperature, speed, driving style, and terrain.

Long Distance Rating

1.0/ 5.0
Below Average

This rating considers:

  • Real highway range (WLTP: 225 km140 mi)
  • Charging speed and charging time
  • Vehicle efficiency

Quick Overview

  • Brand Nissan
  • WLTP Range 225 km140 mi
  • Battery Capacity 45 kWh
  • DC Fast Charging 80 kW
  • Towing Capacity 1,500 kg3,307 lbs
  • Release Date 10/1/2023
  • Last Updated 5/21/2026
