Mercedes-Benz EQS SUV Maybach 680
Mercedes-Benz logo
Mercedes-Benz

Mercedes-Benz EQS SUV Maybach 680

Available SUV AWD
200.634 € $216,685£170,539
WLTP Range
490 km304 mi
Net Battery
118 kWh
0-100 km/h
4.4s
Peak Power
484 kW
A day with this car
DC 10–80%
33 min
200 kW peak · 160 kW avg
Home wallbox
6h 30m
22 kW AC · 0–100% overnight
Winter highway
353 km219 mi
Cold, 120 km/h class
Charge ports
CCS
Type 2 · right rear

One-stop highway day · 507 km315 mi in 4h 51min

356 km221 mi
3h 14min
15 min
charge
151 km94 mi
1h 22min
WLTP Range
490 km304 mi
Official Combined
Usable Battery
118 kWh
125.0 kWh Gross
Peak Power
484 kW
649 hp
0-100 km/h
4.4 s
Max: 210 km/h130 mph
DC Fast Peak
200 kW
High-Power DC

Performance & Powertrain

AWD Dedicated EV Platform
Total System Power 484 kW (649 hp)
Total System Torque 950 Nm
0-100 km/h Sprint 4.4 s
Top Speed 210 km/h130 mph
Drivetrain Configuration AWD
Platform Code Mercedes-Benz EVA2

Battery Engineering & Chemistry

400 V No Data
Usable Battery Capacity 118 kWh
Nominal Battery Capacity 125.0 kWh
Battery Type Lithium-ion
Cell Form Factor No Data
Nominal Voltage No Data
Total Cell Count No Data
Pack Configuration No Data
Manufacturer Battery Warranty 10 years / 250,000 km155 mi

Dimensions, Cargo & Towing

Towing: 1800 kg Frunk: 0 L0.0 cu ft
Boot Cargo Volume 440 L15.5 cu ft
Max Cargo (Seats Down) 440 L15.5 cu ft
Front Trunk (Frunk) 0 L0.0 cu ft
Unladen Curb Weight 3,075 kg6,779 lbs
Overall Length 5125 mm201.8 in
Width (with mirrors) 2157 mm84.9 in
Overall Height 1725 mm67.9 in
Wheelbase 3210 mm126.4 in
Towing Capacity (Braked) 1,800 kg3,968 lbs
Towing Capacity (Unbraked) 750 kg1,653 lbs
Gross Vehicle Weight (GVWR) 3500 kg7,716 lbs
Max Payload Capacity 500 kg1,102 lbs

Cabin, Chassis & Thermal Management

Seating Capacity 4 people seats
Isofix Anchor Points No Data
Turning Circle 11 m36.1 ft
Market Segment JF - Luxury
Roof Rails No
Heat Pump Standard Equipment

Estimated Range by Weather & Road

Efficiency: 220 Wh/km354 Wh/mi

Estimates, not measurements: the WLTP figure scaled by the same temperature and road factors for every car (for example 65% for cold motorway driving, 115% for mild city driving). Your range depends on speed, wheels, load and heating. For a planned stop, use the charging simulator.

Estimated Range Envelope
Cold Highway: 319 km198 mi | Mild Urban: 564 km350 mi
Worst-Case Winter Highway WLTP Lab: 490 km304 mi Best-Case Mild Urban
❄️ Cold Winter (-10°C)
Cabin Heat On
City Driving
Urban stop-and-go
363 km226 mi
Highway Cruising
Motorway speeds
319 km198 mi
Combined Cycle
Everyday winter commute
343 km213 mi
☀️ Mild Summer (23°C)
Optimal Temperature
City Driving
Peak regen recovery
564 km350 mi
Highway Cruising
Motorway speeds
402 km250 mi
Combined Cycle
Ideal mixed-use range
470 km292 mi
High-Power Road Trips

DC Ultra-Fast Charging (10% to 80%)

⚡ CCS2 High-Power
Peak Intake
200 kW DC
Maximum Power
10-80% Session
33 min
Typical Road Stop
Average Power
160 kW DC
Sustained Rate
Range Added
620 km/h385 mph
Added per Hour
Plug & Charge (ISO 15118) Yes
Battery Preconditioning Auto via Nav
Autocharge Protocol Yes
Home & Overnight

AC Destination & Wallbox Charging (0% to 100%)

Type 2 Inverter
Max AC Power
22 kW AC
3-Phase Wallbox
0-100% Duration
6h30m
Full Overnight Charge
Charge Speed
78 km/h48 mph
Range per Hour
Port Location
Right Side - Rear
Body Placement
Mobile Power Station

Bidirectional Charging Capabilities (V2X)

V2L (Vehicle-to-Load)
Camping & devices
-
V2H (Vehicle-to-Home)
Emergency backup
Not supported
V2G (Vehicle-to-Grid)
Grid arbitrage
Not supported

Highway Endurance Score

EVDB Index
3.0/ 5.0
Capable Long-Distance EV

Calculated from sustained 10-80% DC fast charging speed, cold-weather aerodynamic drag, and official WLTP range (490 km304 mi).

Vehicle Overview

  • Manufacturer Mercedes-Benz
  • WLTP Range 490 km304 mi
  • Net Battery 118 kWh
  • DC Fast Charging 200 kW
  • Towing Capacity 1,800 kg3,968 lbs
  • Market Availability Available
  • Release Date 1/1/2024
  • Telemetry Verified 5/21/2026
Frequently Asked Questions

Mercedes-Benz EQS SUV Maybach 680 Range & Charging FAQ

What is the real-world highway and winter range of the Mercedes-Benz EQS SUV Maybach 680?

The official combined WLTP range for the Mercedes-Benz EQS SUV Maybach 680 is 490 km (304 miles).

In cold winter conditions (-5°C / 23°F) at highway cruising speeds (120-130 km/h), expect a realistic highway range of approximately 353 km (219 miles) due to cold battery chemistry, cabin heating, and higher aerodynamic drag.

How long does it take to charge the Mercedes-Benz EQS SUV Maybach 680 at home?

Charging the 118 kWh battery from 0% to 100% takes approximately 9.7 hours using a standard 11 kW 3-phase AC wallbox. On a single-phase 7.4 kW home charger, a full charge takes around 14.4 hours (typically overnight).

How fast is DC fast charging (10% to 80%)?

The Mercedes-Benz EQS SUV Maybach 680 supports peak DC fast charging rates of up to 200 kW. Recharging from 10% to 80% State of Charge (SoC) requires approximately 34 minutes at a compatible ultra-rapid charging station.

How much does it cost to charge the Mercedes-Benz EQS SUV Maybach 680?

At an average European residential electricity tariff of €0.24/kWh, a complete 0-100% home charge costs approximately €28.32. At high-power public DC charging networks (~€0.65/kWh), a full recharge costs approximately €76.70.
