Mercedes-Benz CLA Shooting Brake 200
Mercedes-Benz logo
Mercedes-Benz

Mercedes-Benz CLA Shooting Brake 200

Available Wagon RWD
50.789 € $54,852£43,171
WLTP Range
385 km239 mi
Net Battery
58 kWh
0-100 km/h
7.6s
Peak Power
165 kW
A day with this car
DC 10–80%
200 kW
10–80 time not listed
Home wallbox
6h 15m
11 kW AC · 0–100% overnight
Winter highway
277 km172 mi
Cold, 120 km/h class
Charge ports
CCS
Type 2 · right rear

One-stop highway day · 475 km295 mi in 4h 34min

287 km178 mi
2h 36min
15 min
charge
189 km117 mi
1h 43min
WLTP Range
385 km239 mi
Official Combined
Usable Battery
58 kWh
60.0 kWh Gross
Peak Power
165 kW
221 hp
0-100 km/h
7.6 s
Max: 210 km/h130 mph
DC Fast Peak
200 kW
High-Power DC

Performance & Powertrain

RWD Dedicated EV Platform
Total System Power 165 kW (221 hp)
Total System Torque 335 Nm
0-100 km/h Sprint 7.6 s
Top Speed 210 km/h130 mph
Drivetrain Configuration RWD
Platform Code Mercedes-Benz MMA

Battery Engineering & Chemistry

⚡ 800V Architecture LFP
Usable Battery Capacity 58 kWh
Nominal Battery Capacity 60.0 kWh
Battery Type Lithium-ion
Cell Form Factor Prismatic
Nominal Voltage No Data
Total Cell Count 192
Pack Configuration 192s1p
Manufacturer Battery Warranty 8 years / 160,000 km99 mi

Dimensions, Cargo & Towing

Towing: 1500 kg Frunk: 101 L3.6 cu ft
Boot Cargo Volume 540 L19.1 cu ft
Max Cargo (Seats Down) 1290 L45.6 cu ft
Front Trunk (Frunk) 101 L3.6 cu ft
Unladen Curb Weight 2,065 kg4,553 lbs
Overall Length 4723 mm185.9 in
Width (with mirrors) 2021 mm79.6 in
Overall Height 1469 mm57.8 in
Wheelbase 2790 mm109.8 in
Towing Capacity (Braked) 1,500 kg3,307 lbs
Towing Capacity (Unbraked) 750 kg1,653 lbs
Gross Vehicle Weight (GVWR) 2525 kg5,567 lbs
Max Payload Capacity 535 kg1,179 lbs

Cabin, Chassis & Thermal Management

Seating Capacity 5 people seats
Isofix Anchor Points No Data
Turning Circle 11.2 m36.7 ft
Market Segment D - Large
Roof Rails No
Heat Pump Standard Equipment

Euro NCAP Safety Assessment

★★★★★ 5 Stars (2025)
Adult Occupant Protection 94%
Child Occupant Protection 89%
Vulnerable Road Users (Pedestrians) 93%
Active Safety Assist Systems 85%

Estimated Range by Weather & Road

Efficiency: 151 Wh/km243 Wh/mi

Estimates, not measurements: the WLTP figure scaled by the same temperature and road factors for every car (for example 65% for cold motorway driving, 115% for mild city driving). Your range depends on speed, wheels, load and heating. For a planned stop, use the charging simulator.

Estimated Range Envelope
Cold Highway: 250 km155 mi | Mild Urban: 443 km275 mi
Worst-Case Winter Highway WLTP Lab: 385 km239 mi Best-Case Mild Urban
❄️ Cold Winter (-10°C)
Cabin Heat On
City Driving
Urban stop-and-go
285 km177 mi
Highway Cruising
Motorway speeds
250 km155 mi
Combined Cycle
Everyday winter commute
270 km168 mi
☀️ Mild Summer (23°C)
Optimal Temperature
City Driving
Peak regen recovery
443 km275 mi
Highway Cruising
Motorway speeds
316 km196 mi
Combined Cycle
Ideal mixed-use range
370 km230 mi
High-Power Road Trips

DC Ultra-Fast Charging (10% to 80%)

⚡ CCS2 High-Power
Peak Intake
200 kW DC
Maximum Power
10-80% Session
~25 min
Typical Road Stop
Average Power
125 kW DC
Sustained Rate
Range Added
770 km/h478 mph
Added per Hour
Plug & Charge (ISO 15118) Yes
Battery Preconditioning Auto via Nav
Autocharge Protocol Yes
Home & Overnight

AC Destination & Wallbox Charging (0% to 100%)

Type 2 Inverter
Max AC Power
11 kW AC
3-Phase Wallbox
0-100% Duration
6h15m
Full Overnight Charge
Charge Speed
62 km/h39 mph
Range per Hour
Port Location
Right Side - Rear
Body Placement
Mobile Power Station

Bidirectional Charging Capabilities (V2X)

V2L (Vehicle-to-Load)
Camping & devices
-
V2H (Vehicle-to-Home)
Emergency backup
Not supported
V2G (Vehicle-to-Grid)
Grid arbitrage
Not supported

Highway Endurance Score

EVDB Index
3.0/ 5.0
Capable Long-Distance EV

Calculated from sustained 10-80% DC fast charging speed, cold-weather aerodynamic drag, and official WLTP range (385 km239 mi).

Vehicle Overview

  • Manufacturer Mercedes-Benz
  • WLTP Range 385 km239 mi
  • Net Battery 58 kWh
  • DC Fast Charging 200 kW
  • Towing Capacity 1,500 kg3,307 lbs
  • Market Availability Available
  • Release Date 4/1/2026
  • Telemetry Verified 7/5/2026
Frequently Asked Questions

Mercedes-Benz CLA Shooting Brake 200 Range & Charging FAQ

What is the real-world highway and winter range of the Mercedes-Benz CLA Shooting Brake 200?

The official combined WLTP range for the Mercedes-Benz CLA Shooting Brake 200 is 385 km (239 miles).

In cold winter conditions (-5°C / 23°F) at highway cruising speeds (120-130 km/h), expect a realistic highway range of approximately 277 km (172 miles) due to cold battery chemistry, cabin heating, and higher aerodynamic drag.

How long does it take to charge the Mercedes-Benz CLA Shooting Brake 200 at home?

Charging the 58 kWh battery from 0% to 100% takes approximately 4.7 hours using a standard 11 kW 3-phase AC wallbox. On a single-phase 7.4 kW home charger, a full charge takes around 7.1 hours (typically overnight).

How fast is DC fast charging (10% to 80%)?

The Mercedes-Benz CLA Shooting Brake 200 supports peak DC fast charging rates of up to 200 kW. Recharging from 10% to 80% State of Charge (SoC) requires approximately 17 minutes at a compatible ultra-rapid charging station.

How much does it cost to charge the Mercedes-Benz CLA Shooting Brake 200?

At an average European residential electricity tariff of €0.24/kWh, a complete 0-100% home charge costs approximately €13.92. At high-power public DC charging networks (~€0.65/kWh), a full recharge costs approximately €37.70.
