Fiat 500e 3+1 24 kWh
Fiat logo
Fiat

Fiat 500e 3+1 24 kWh

Available Hatchback FWD
29.990 € $32,389£25,492
WLTP Range
135 km84 mi
Net Battery
21.3 kWh
0-100 km/h
9s
Peak Power
70 kW
A day with this car
DC 10–80%
24 min
50 kW peak · 40 kW avg
Home wallbox
2h 30m
11 kW AC · 0–100% overnight
Winter highway
97 km60 mi
Cold, 120 km/h class
Charge ports
CCS
Type 2 · right rear

One-stop highway day · 153 km95 mi in 1h 38min

97 km60 mi
53min
15 min
charge
55 km34 mi
30min
WLTP Range
135 km84 mi
Official Combined
Usable Battery
21.3 kWh
23.8 kWh Gross
Peak Power
70 kW
94 hp
0-100 km/h
9 s
Max: 135 km/h84 mph
DC Fast Peak
50 kW
High-Power DC

Performance & Powertrain

FWD Dedicated EV Platform
Total System Power 70 kW (94 hp)
Total System Torque 220 Nm
0-100 km/h Sprint 9 s
Top Speed 135 km/h84 mph
Drivetrain Configuration FWD
Platform Code STLA City

Battery Engineering & Chemistry

400 V NMC
Usable Battery Capacity 21.3 kWh
Nominal Battery Capacity 23.8 kWh
Battery Type Lithium-ion
Cell Form Factor Prismatic
Nominal Voltage 400 V
Total Cell Count 108
Pack Configuration 108s1p
Manufacturer Battery Warranty 8 years / 160,000 km99 mi

Dimensions, Cargo & Towing

Frunk: 0 L0.0 cu ft
Boot Cargo Volume 185 L6.5 cu ft
Max Cargo (Seats Down) 550 L19.4 cu ft
Front Trunk (Frunk) 0 L0.0 cu ft
Unladen Curb Weight 1,290 kg2,844 lbs
Overall Length 3631 mm143.0 in
Width (with mirrors) 1900 mm74.8 in
Overall Height 1529 mm60.2 in
Wheelbase 2322 mm91.4 in
0
Towing Capacity (Unbraked) 0 kg0 lbs
Gross Vehicle Weight (GVWR) No Data
Max Payload Capacity No Data

Cabin, Chassis & Thermal Management

Seating Capacity 4 people seats
Isofix Anchor Points No Data
Turning Circle 9.7 m31.8 ft
Market Segment B - Compact
Roof Rails No
Heat Pump No

Euro NCAP Safety Assessment

★★★★ 4 Stars (2021)
Adult Occupant Protection 76%
Child Occupant Protection 80%
Vulnerable Road Users (Pedestrians) 67%
Active Safety Assist Systems 67%

Estimated Range by Weather & Road

Efficiency: 158 Wh/km254 Wh/mi

Estimates, not measurements: the WLTP figure scaled by the same temperature and road factors for every car (for example 65% for cold motorway driving, 115% for mild city driving). Your range depends on speed, wheels, load and heating. For a planned stop, use the charging simulator.

Estimated Range Envelope
Cold Highway: 88 km55 mi | Mild Urban: 155 km96 mi
Worst-Case Winter Highway WLTP Lab: 135 km84 mi Best-Case Mild Urban
❄️ Cold Winter (-10°C)
Cabin Heat On
City Driving
Urban stop-and-go
100 km62 mi
Highway Cruising
Motorway speeds
88 km55 mi
Combined Cycle
Everyday winter commute
95 km59 mi
☀️ Mild Summer (23°C)
Optimal Temperature
City Driving
Peak regen recovery
155 km96 mi
Highway Cruising
Motorway speeds
111 km69 mi
Combined Cycle
Ideal mixed-use range
130 km81 mi
High-Power Road Trips

DC Ultra-Fast Charging (10% to 80%)

⚡ CCS2 High-Power
Peak Intake
50 kW DC
Maximum Power
10-80% Session
24 min
Typical Road Stop
Average Power
40 kW DC
Sustained Rate
Range Added
230 km/h143 mph
Added per Hour
Plug & Charge (ISO 15118) No
Battery Preconditioning Auto via Nav
Autocharge Protocol Yes
Home & Overnight

AC Destination & Wallbox Charging (0% to 100%)

Type 2 Inverter
Max AC Power
11 kW AC
3-Phase Wallbox
0-100% Duration
2h30m
Full Overnight Charge
Charge Speed
59 km/h37 mph
Range per Hour
Port Location
Right Side - Rear
Body Placement
Mobile Power Station

Bidirectional Charging Capabilities (V2X)

V2L (Vehicle-to-Load)
Camping & devices
-
V2H (Vehicle-to-Home)
Emergency backup
Not supported
V2G (Vehicle-to-Grid)
Grid arbitrage
Not supported

Highway Endurance Score

Rating calculation pending live road testing.

Vehicle Overview

  • Manufacturer Fiat
  • WLTP Range 135 km84 mi
  • Net Battery 21.3 kWh
  • DC Fast Charging 50 kW
  • Towing Capacity No Towing
  • Market Availability Available
  • Release Date 7/1/2022
  • Telemetry Verified 5/24/2026
Frequently Asked Questions

Fiat 500e 3+1 24 kWh Range & Charging FAQ

What is the real-world highway and winter range of the Fiat 500e 3+1 24 kWh?

The official combined WLTP range for the Fiat 500e 3+1 24 kWh is 135 km (84 miles).

Compare with the Fiat 500e 3+1.

In cold winter conditions (-5°C / 23°F) at highway cruising speeds (120-130 km/h), expect a realistic highway range of approximately 97 km (60 miles) due to cold battery chemistry, cabin heating, and higher aerodynamic drag.

How long does it take to charge the Fiat 500e 3+1 24 kWh at home?

Charging the 21.3 kWh battery from 0% to 100% takes approximately 1.7 hours using a standard 11 kW 3-phase AC wallbox. On a single-phase 7.4 kW home charger, a full charge takes around 2.6 hours (typically overnight).

How fast is DC fast charging (10% to 80%)?

The Fiat 500e 3+1 24 kWh supports peak DC fast charging rates of up to 50 kW. Recharging from 10% to 80% State of Charge (SoC) requires approximately 25 minutes at a compatible ultra-rapid charging station.

How much does it cost to charge the Fiat 500e 3+1 24 kWh?

At an average European residential electricity tariff of €0.24/kWh, a complete 0-100% home charge costs approximately €5.11. At high-power public DC charging networks (~€0.65/kWh), a full recharge costs approximately €13.85.
