BYD DOLPHIN SURF 30 kWh Active
BYD logo
BYD

BYD DOLPHIN SURF 30 kWh Active

Available Hatchback FWD
22.990 € $24,829£19,542
WLTP Range
190 km118 mi
Net Battery
30 kWh
0-100 km/h
11.1s
Peak Power
65 kW
A day with this car
DC 10–80%
29 min
65 kW peak · 45 kW avg
Home wallbox
3h 15m
11 kW AC · 0–100% overnight
Winter highway
137 km85 mi
Cold, 120 km/h class
Charge ports
CCS
Type 2 · right front

One-stop highway day · 199 km124 mi in 2h 3min

133 km83 mi
1h 12min
15 min
charge
66 km41 mi
36min
WLTP Range
190 km118 mi
Official Combined
Usable Battery
30 kWh
32.0 kWh Gross
Peak Power
65 kW
87 hp
0-100 km/h
11.1 s
Max: 150 km/h93 mph
DC Fast Peak
65 kW
High-Power DC

Performance & Powertrain

FWD Dedicated EV Platform
Total System Power 65 kW (87 hp)
Total System Torque 175 Nm
0-100 km/h Sprint 11.1 s
Top Speed 150 km/h93 mph
Drivetrain Configuration FWD
Platform Code BYD e-Platform 3.0

Battery Engineering & Chemistry

400 V LFP
Usable Battery Capacity 30 kWh
Nominal Battery Capacity 32.0 kWh
Battery Type Lithium-ion
Cell Form Factor Prismatic
Nominal Voltage 301 V
Total Cell Count 94
Pack Configuration 94s1p
Manufacturer Battery Warranty 8 years / 250,000 km155 mi

Dimensions, Cargo & Towing

Frunk: 0 L0.0 cu ft
Boot Cargo Volume 308 L10.9 cu ft
Max Cargo (Seats Down) 1037 L36.6 cu ft
Front Trunk (Frunk) 0 L0.0 cu ft
Unladen Curb Weight 1,369 kg3,018 lbs
Overall Length 3990 mm157.1 in
Width (with mirrors) 1970 mm77.6 in
Overall Height 1590 mm62.6 in
Wheelbase 2500 mm98.4 in
0
Towing Capacity (Unbraked) 0 kg0 lbs
Gross Vehicle Weight (GVWR) 1638 kg3,611 lbs
Max Payload Capacity 344 kg758 lbs

Cabin, Chassis & Thermal Management

Seating Capacity 4 people seats
Isofix Anchor Points Yes, 3 seats
Turning Circle 9.9 m32.5 ft
Market Segment B - Compact
Roof Rails No
Heat Pump Varies by country

Euro NCAP Safety Assessment

★★★★ 4 Stars (2025)
Adult Occupant Protection 82%
Child Occupant Protection 86%
Vulnerable Road Users (Pedestrians) 76%
Active Safety Assist Systems 77%

Estimated Range by Weather & Road

Efficiency: 158 Wh/km254 Wh/mi

Estimates, not measurements: the WLTP figure scaled by the same temperature and road factors for every car (for example 65% for cold motorway driving, 115% for mild city driving). Your range depends on speed, wheels, load and heating. For a planned stop, use the charging simulator.

Estimated Range Envelope
Cold Highway: 124 km77 mi | Mild Urban: 218 km135 mi
Worst-Case Winter Highway WLTP Lab: 190 km118 mi Best-Case Mild Urban
❄️ Cold Winter (-10°C)
Cabin Heat On
City Driving
Urban stop-and-go
141 km88 mi
Highway Cruising
Motorway speeds
124 km77 mi
Combined Cycle
Everyday winter commute
133 km83 mi
☀️ Mild Summer (23°C)
Optimal Temperature
City Driving
Peak regen recovery
218 km135 mi
Highway Cruising
Motorway speeds
156 km97 mi
Combined Cycle
Ideal mixed-use range
182 km113 mi
High-Power Road Trips

DC Ultra-Fast Charging (10% to 80%)

⚡ CCS2 High-Power
Peak Intake
65 kW DC
Maximum Power
10-80% Session
29 min
Typical Road Stop
Average Power
45 kW DC
Sustained Rate
Range Added
270 km/h168 mph
Added per Hour
Plug & Charge (ISO 15118) No
Battery Preconditioning Auto via Nav
Autocharge Protocol Yes
Home & Overnight

AC Destination & Wallbox Charging (0% to 100%)

Type 2 Inverter
Max AC Power
11 kW AC
3-Phase Wallbox
0-100% Duration
3h15m
Full Overnight Charge
Charge Speed
59 km/h37 mph
Range per Hour
Port Location
Right Side - Front
Body Placement
Mobile Power Station

Bidirectional Charging Capabilities (V2X)

V2L (Vehicle-to-Load)
Camping & devices
3.3 kW AC
V2H (Vehicle-to-Home)
Emergency backup
Not supported
V2G (Vehicle-to-Grid)
Grid arbitrage
Not supported

Highway Endurance Score

Rating calculation pending live road testing.

Vehicle Overview

  • Manufacturer BYD
  • WLTP Range 190 km118 mi
  • Net Battery 30 kWh
  • DC Fast Charging 65 kW
  • Towing Capacity No Towing
  • Market Availability Available
  • Release Date 5/1/2025
  • Telemetry Verified 5/19/2026
Frequently Asked Questions

BYD DOLPHIN SURF 30 kWh Active Range & Charging FAQ

What is the real-world highway and winter range of the BYD DOLPHIN SURF 30 kWh Active?

The official combined WLTP range for the BYD DOLPHIN SURF 30 kWh Active is 190 km (118 miles).

In cold winter conditions (-5°C / 23°F) at highway cruising speeds (120-130 km/h), expect a realistic highway range of approximately 137 km (85 miles) due to cold battery chemistry, cabin heating, and higher aerodynamic drag.

How long does it take to charge the BYD DOLPHIN SURF 30 kWh Active at home?

Charging the 30 kWh battery from 0% to 100% takes approximately 2.5 hours using a standard 11 kW 3-phase AC wallbox. On a single-phase 7.4 kW home charger, a full charge takes around 3.6 hours (typically overnight).

How fast is DC fast charging (10% to 80%)?

The BYD DOLPHIN SURF 30 kWh Active supports peak DC fast charging rates of up to 65 kW. Recharging from 10% to 80% State of Charge (SoC) requires approximately 27 minutes at a compatible ultra-rapid charging station.

How much does it cost to charge the BYD DOLPHIN SURF 30 kWh Active?

At an average European residential electricity tariff of €0.24/kWh, a complete 0-100% home charge costs approximately €7.20. At high-power public DC charging networks (~€0.65/kWh), a full recharge costs approximately €19.50.
